Name: Bimba-Mead Air Pilot Valve M4A230C-06, 5 Port, 3 Pos, Dbl Control, 1/8&quot; NPT, Closed Center, Cv=0.67
SKU: Bimba-Mead WBB571918
Availability: InStock

New

Bimba-Mead Air Pilot Valve M4A230C-06, 5 Port, 3 Pos, Dbl Control, 1/8" NPT, Closed Center, Cv=0.67

Original price was: $61.95.Current price is: $43.37.

SKU: Bimba-Mead WBB571918 Categories: Directional Control Valves, Pneumatic System Components, Valves Tags: 22 to 120 PSI psi, 23∼140 °F, 3 Cycles/Sec, 5 Port 3 Position, Bimba-Mead, External control, Motors & Power Transmission, Not Required

Quality You Can Count On
Control the delivery date and try to deliver it in the fastest time
Unbeatable Quality Guaranteed
Reliable Payments for Reliable Shopping

Bimba-Mead Air Pilot Valve M4A230C-06, 5 Port, 3 Pos, Dbl Control, 1/8″ NPT, Closed Center, Cv=0.67

M4A230C-06 double air piloted valves are 4-way, 1/8 in NPT port, spool style valves with closed center. They are stackable and provide a 3-position, normally closed, closed center operation. The M4A230C-06 series valves can be used in individual valve applications or multiple valves can be assembled together on a manifold to share supply air which simplifies the piping. They are compatible with the M200M series manifolds.

Port Size	1/8 NPT in
Height	1-3/8 in
Length	4-3/8 in
Width	7/8 in
Type	5 Port 3 Position
Lubrication	Not Required
Pressure	22 to 120 PSI psi
Actuation	External control
Temperature Range	23∼140 °F
Max Frequency	3 Cycles/Sec
Manufacturers Part Number	M4A230C-06
Media	Air
Flow Coefficient	Cv = 0.67
Brand	Bimba-Mead
