Name: Bimba-Mead Push-Pull Valve M4L310-08, 5 Port, 2 Pos, 1/4&quot; NPT
SKU: Bimba-Mead WBB572013
Availability: InStock

New

Bimba-Mead Push-Pull Valve M4L310-08, 5 Port, 2 Pos, 1/4" NPT

Original price was: $44.95.Current price is: $31.47.

SKU: Bimba-Mead WBB572013 Categories: Directional Control Valves, Pneumatic System Components, Valves Tags: 0 to 120 PSI psi, 23 to 140 °F, 5 Port - 2 Position Detented, Air, Bimba-Mead, Cv = 1.39, M4L310-08, Motors & Power Transmission

Quality You Can Count On
Control the delivery date and try to deliver it in the fastest time
Unbeatable Quality Guaranteed
Reliable Payments for Reliable Shopping

Bimba-Mead Push-Pull Valve M4L310-08, 5 Port, 2 Pos, 1/4″ NPT

M4L310-08 push-pull direct acting valves are 4-way, 1/4 in NPT port, spool style valve, provide a 2-position, manual return operation. The M4L310-08 is a manual operation stand alone valve with smooth actuation and reliable orientation. The valve can be body or panel mount.

Port Size	1/4 NPT in
Height	4-1/2 in
Length	1-37/64 in
Width	1-1/16 in
Temperature Range	23 to 140 °F
Fluid	Air
Type	5 Port – 2 Position Detented
Manufacturers Part Number	M4L310-08
Pressure	0 to 120 PSI psi
Flow Coefficient	Cv = 1.39
Brand	Bimba-Mead
